HVD 55 Oil Injected, Direct Coupled, Variable Speed Rotary Screw Air Compressor

Description

Hertz HVD 55 – 75 HP Variable Speed Base Mount Rotary Screw Air Compressor

The Hertz HVD 55 is a powerhouse 75 HP variable speed base mount rotary screw air compressor designed for demanding industrial applications that require continuous-duty performance and maximum efficiency. With its advanced variable speed drive, the HVD 55 precisely adjusts airflow to match your facility’s real-time demand—reducing energy waste and operating costs while delivering reliable compressed air. Rugged and base-mounted, this model is ideal for large plants with existing air storage or customized compressed air systems.

Key Features & Benefits

• 75 HP Motor – engineered for heavy-duty, large-scale operations

• Variable Speed Drive (VSD) – minimizes energy use by adapting output to demand

• Base Mount Design – flexible installation Airflow Capacity – delivers up to 351 CFM @ 100 PSI

• Durable Engineering – long service life with high-quality, easy-to-maintain components

• Low Noise Performance – built for quieter operation in plant environments

• Smart Electronic Controls – intuitive interface with alarms, scheduling, and maintenance reminders

Technical Specifications

• Model: HVD 55

• Motor Power: 75 HP / 55 kW

• Voltage Options: 230V/3Ph and 460V/3Ph

• Pressure Range: 100–175 PSI

• Capacity:

  • 100 PSI: 94–351 CFM

  • 125 PSI: 97–334 CFM

  • 150 PSI: 97–309 CFM

  • 175 PSI: 153–266 CFM

• Connection: 2” NPT

• Dimensions (L x W x H): 91” x 54” x 82”

• Weight: 4,840 lbs
